Screen: ≤ 15.6"†

Capacity: ≤ 3.4 kg

Part Number:

• Australia/New Zealand = DM40-2008-4

Description: Zip40 Charging and Management Cart (grey/white)

• Includes 40 dividers, 9 small device divider stoppers, 3 m country-specific power cord, 4 country-specific 10-outlet power strips, two 20-unit brick storage trays, four 5ʺ dual-wheel locking casters, external auxiliary outlet (2 receptacles in US, JP or 1 receptacle in EU, UK, AU, CN), 2 mounting brackets for Ethernet switch, 2 internal auxiliary outlets for Ethernet switch and WAP installation, power on/off switch, 2 keys, 40 CAT6 Ethernet cables, 3 Ethernet cable storage trays, one 5.9 m CAT6 Ethernet cable, Velcro cable management straps

Ships fully assembled

Total Capacity: Up to 40 devices with 1.1"-wide (28 mm) slot; up to 30 devices with 1.9"-wide (48 mm) slot

Maximum device dimensions: 17.1ʺW x 11.2ʺH (43.4 x 28.4 cm) including case and cord Divider bumpers shorten the slot size to provide easy plug-in access for smaller tablet devices Maximum adapter dimensions: Brick-style AC adapter = 7ʺH x 3ʺW x 2.2ʺD (17.8 x 7.6 x 5.6 cm). Wall-plug-style AC adapter = 2.2ʺW x 4.7ʺL x 3.9ʺD (5.5 x 12 x 10 cm) including cable strain relief. Cable diameter = 2.6–4.6 mm Weight capacity: Total = 116 kg; 34.7 kg per shelf (3 shelves total in cart); 11.3 kg top worksurface. Per device maximum weight of 3.4 kg assumes 10 devices per shelf in a cart configured to hold 30 devices in total Compatible with Apple’s eighth-generation iPad Country-specific 10-receptacle outlet strip is designed to work with oversized wall-style and brick-style AC adapters Uses the AC adapters that come with each device. AC adapters are not included

Cooling/Ventilation: Four 12V DC continuous operation fans and ventilated doors keep equipment cool External Auxiliary Outlet(s) give you an always-on outlet to plug in extra peripherals like printers or document cameras. No need to choose between using the auxiliary outlets and charging devices—do both at the same time! Location included for installation of a Wireless Access Point (WAP not included). Maximum dimensions of the WAP = 10ʺW x 10ʺD x 2.2ʺH (25.4 x 25.4 x 5.6 cm) Location included for installation of a standard 1U rack mountable Ethernet Switch (switch not included). Maximum dimensions of the switch = 17.5ʺW x 12.4ʺD x 1.8ʺH (44 x 26 x 4.4 cm). Maximum weight of the switch = 5.4 kg Country-specific power cord =3.8 m long; stored on a recessed cord wrap

Environmentally clean: RoHS, REACH, WEEE and EU (94/620EC) packaging compliant

Power System: input/output = 100-240V~, 12-10A, 50/60 Hz

Temperature Range: operating 0° to 30°C; storage -40°C to -60°C

Relative Humidity (maximum): operating 10 to 90% (non-condensing); storage 5% to 95% (non-condensing)

Altitude (maximum): 2000 m

Certification UL/IEC 62368-1 and CSA C22 2 No. 62368-1 for Safety of Information Technology Equipment; UL 1678 Household, Commercial, and Institutional-Use Carts, Stands, and Entertainment Centers for Use with Audio and/or Video Equipment ICES-003 Issue 4, Class A FCC Part 15 Class RoHS and Reach compliant material used

Product Dimensions: 77 x 66 x 115 cm

Product Weight: 82 kg

Shipping Dimensions: 94 x 75 x 132 cm

Shipping Weight: 103 kg

Warranty: Limited lifetime for the frame; five years for other mechanical components; three years for electrical components; one year for cables
